Commercial Entrance Automatic Sliding Door Drive System

ℹ️

Basic Specifications

Model NO.

F-150W

Open Style

Sliding

Opening Type

Induced

Special Function

Soundproof

Color

Silver

Certification

ISO9001, RoHS, CE

Position

Commercial

Surface Finishing

Finished

Supply Voltage

AC90V/220V; 50-60Hz

Guarantee

3 Years Warranty

Max Door Weight

150kg

Motor Type

24V DC Brushless

🏭

Manufacturing Excellence

Our facility was established in 2003. We specialize in the design and production of automatic sliding doors and automatic swing door openers. By manufacturing aluminum alloy parts in-house, we maintain strict control over product quality and ensure competitive pricing. All products carry CE, IP66, and IP67 approvals.

⭐

Product Advantages

Easy and fast installation

Independent adjustment of force and speed

Controller with Built-in wide voltage

Nylon reinforced belt for quiet operation

Brushless no-maintenance DC gear motor

Supports door weight up to 150kgs

24 Month manufacturers warranty

CE / ISO 9001:2000 Certified

🖼️

Product Gallery

📊

Technical Parameters

Drive Direction	Single-parting / Bi-Parting
Maximum Door Weight	1 × 150kg (Single) / 2 x 150kg (Bi)
Motor Power	75W
Opening Speed Range	0.4 - 0.7m / s (adjustable)
Closing Speed Range	0.3 - 0.6m / s (adjustable)
Power Supply	90-220VAC±10%, 50HZ, 10A
UPS Backup Battery	30 mins
Ambient Temperature	-15°C to 50°C
Protection Level	IP23
Opening Width (W)	600-3000mm

❓

Frequently Asked Questions

Q1: What is the maximum door weight this system can handle? A: The F-150W system can support up to 150kg for a single leaf or 2 x 150kg for double leaf configurations.

Q2: Does the system work during power outages? A: Yes, it includes a UPS backup battery that provides approximately 30 minutes of operation during a power failure.

Q3: Is the motor noisy? A: No, the system uses a brushless DC gear motor combined with a nylon reinforced belt to ensure quiet and smooth operation.

Q4: What certifications do these doors have? A: Our products are fully certified with CE, ISO9001:2000, and RoHS standards.

Q5: Can the opening and closing speeds be adjusted? A: Yes, both opening (0.4-0.7m/s) and closing (0.3-0.6m/s) speeds are fully adjustable via the controller.

Q6: What is the warranty period? A: We offer a 24-month manufacturer warranty on the drive system for peace of mind.
